Features:
Strong Zinc Alloy Electroplated anti-vandal case
Full programming from the keypad
2000 users, supports Card, PIN, Card+PIN
Can be used as a standalone keypad
Backlight keys
Wiegand 26 input for connection to external reader or Wiegand 26 output for connection to a controller
Adjustable Door Output time, Alarm time, Door Open time
Very low power consumption (30mA)
Fast operating speed, <20ms with 2000 users
Lock output current short circuit protection
Easy to install and program
Built in light dependent resistor (LDR) for anti tamper
Built in buzzer
Red, Yellow and Green LEDs display the working status
Support four digits worked as stand-alone keypad

Specifications:
Operating Voltage: 12VDC
User Capacity: 2000
Card Reading Distance: 3-6cm / 1.2-2.4in
Frequency: 125KHZ
Active Current: <60mA
Idle Current: 25±5mA
Lock Output Load: Max 3A
Alarm Output Load: Max 20A
Operating Temperature: -45℃~60℃ / -49℉~140℉
Operating Humidity: 10%~90% RH
Adjustable Door Relay Time: 0-99 seconds
Adjustable Alarm Time: 0-3 minutes
Wiegand Interface: Wiegand 26 bit
Wiring Connections: Electric Lock, Exit Button, External Alarm
Product Size: 155x45x20mm / 6.1x1.8x0.8in
Package weight: 330g / 0.73lb

Installation:
Remove the back cover from the keypad using the supplied special screw driver
Drill 2 holes on the wall for the Self tapping screws and 1 hole for the cable
Put the supplied rubber bungs into the 2 holes
Fix the back cover firmly on the wall with 2 Self tapping screws
Thread the cable through the cable hole
Attach the keypad to the back cover

Package includes:
1 x Access Control Keypad
1 x Installation Kit
1 x User Manual
