Features:

No load power consumption <0.5W

All using 105°C long life electrolytic capacitors

Protections: Short circuit / Overload / Over voltage

Meet EMS EN50082-2/EN61000-6-2

heavy industry level (35~150W)

Withstand 300VAC surge input for 5 sec.

High operating temperature up to 70°C

Withstand 5G vibration test

Miniature size, high power density

High efficiency, long life and high reliability

LED indicator for power on

100% full load burn-in test

Suitable for critical applications

3 years warranty

General Specification (Please refer to images below for detailed datasheet)

AC input voltage range:85~264VAC, 120~370VDC

AC inrush current:Cold start, 65A at 230VAC

DC adjustment range:±10% by potentiometer for single output; CH1 -5%~+10% by potentiometer for multiple output

Overload protection:>105%, hiccup mode

Over voltage protection:115%~135%, shut off

Withstand voltage:I/P - O/P: 3kVAC, I/P - FG: 1.5kVAC, O/P - FG: 0.5kVAC, 1 minute

Working temperature:-20~+70°C

Vibration:10~500Hz, 5G 10min. /1 cycle, period for 60 min. each along X, Y, Z axes

Safety standards:UL60950-1, TUV EN60950-1 approved

EMC standards:EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN50082-2) (35~150W)

Connection:Terminal block for input and output

Dimension (LxWxH):62.5x 51x 28

Case No.:971A

Packing:108pcs /15.0kg
