Model: VHD-UHAE is HDMI 2.0b, 18Gpbs, HDCP 2.2, one HDMI input to one HDMI output + Toslink Optical Audio output + 3 5mm stereo headphone jack output. | Support universal video resolutions up to 4Kx2K@60Hz (NTSC) or 50Hz (PAL), YUV4:4:4, RGB & YCbCr 4:4:4, Color Depth 10bit & 12bit, HDR, Dolby Vision. Please use certified 18Gbps HDMI cable under 15ft for guaranteed performance. | Extracts HDMI Audio signal (2CH PCM, Bitstream DTS & Dolby Digital 5.1Ch, and Dolby Digital Plus) to Toslink optical output; extracts 2CH PCM/LPCM to the 3.5mm headphone jack analog output; all higher HDMI audio signals will be available only from the HDMI output / pass through. | Model: VHD-UHAE does not support ARC (Audio Return Channel), for ARC application, please check the latest model "UAEP" or "VHD-UHAE2". | Supports HDMI high bit rate (HBR) Audio pass through Audio sample rates up to 192kHz. 10bits HDR (High Dynamic Range) & Dolby Vision Pass-Through; Support CEC Bypass; If you are interested in this model please also check UHD3X1A and VHD-UHD4X1A models, they have a switch on the front for improved flexibility | Three audio EDID settings: Use 2CH setting for stereo 3.5mm headphone output; 5.1CH setting for optical audio output to 5.1CH surround receiver; use Pass setting for HDMI TV speaker audio. | Lifetime free technical support from u9ltd and ViewHD one year replacement warranty | Package Includes: VHD-UHAE HDMI Audio Extractor, User Manual, 100V-240V AC to 5V DC Power Adapter

The model "VHD-1X2MN3D"may come under two labels: U9 or ViewHD; HDMI 1.3 supports 480i/576i/480p/576p/720p/1080i/1080p + 3D; for 3D application, both of the connected displays must support 3D for 3D to work. | This model is for 1080p@60Hz or lower video. Please check our latest "U9-Pluto" model instead, the U9-Pluto model can completely replace this model and is compatible to HDMI v2.0 source and displays | HDMI 1x2 Splitter provides the same video and audio signals identical to HDMI input signal at both outputs at the same time. | Durable and reliable full metal jacket construction; package includes: universal 100V - 240V AC to DC 5V1A Universal power adapter with US plug, user manual and 1x2 DHMI splitter | Edid duration 4 seconds. This model doesn't support CEC, CEC is not a suitable feature for HDMI splitter, it is good for HDMI switch. | Max Cable extension 10 meters by 28Awg HDMI cable 15 meters by 26Awg HDMI cable | For HDMI 2.0 4k@60 application, check our latest HDMI 2.0 Models: UHD1X2S and UHD1X2SA | Please feel free to contact us if there is any questions, please always contact us when encounter any application problem | ViewHD / U9 one year replacement warranty
