Access control keypad is compact easy to use; metal case; waterproof design; led backlit feature

Easy to install;Plug and Play;easy to install and use Single Door,;Wiegand and reader keypads

Sturdy and backlight function
Metal case with backlight; So it can long use compared with plastic type; also it is easy to operate in the night

Easy Programming
Full programming from the keypad; So it is convenient to modify the programming code to set up a master card

Access Control Ways
Stand alone keypad support 3 access ways: card, password, card + password

Compact
small size make it easily adaptable for a variety of access control requirements; so it can be well placed in garage or office

Easy to use
The user card can be continuously added, and the trouble of inputting the card number is required for each card when the card is added;The operation is simple, the use is convenient, and the management password can be changed

Specification:
Project: Indicators
Power Supply: 12VDC + 10%
Unlock relay: 12VDC/2A
Electric lock output: Max 3A
Alarm output: Max 20A
Output short-circuit protection time: Max 0.1ms
Effective Cards: 2000
Ambient temperature: -45~60 degree centigrade
Relative humidity: 10%-90% RH
Password: 4 digit PIN code
Built-in proximity card reader identify the frequency: ID type: 125KHz
induction card identifying the typeID type: EM
Card reader from: ID type: 5~6 CM
Electric locking interface: Relay output or input of optional
Open access: 1
Doorbell button: 1
Door sensor interface: 1
Interface to an alarm: 1
Add-in Reader Interface: 1 WG26 interface
Size: 110*75*25mm

Package Include:
1X PC Access Control
1X English User Manual
