Sorry - this product is no longer available

BN-220 GPS Module TTL Dual GPS Glonass Navigation with Flash + GPS Passive Antenna for Arduino Raspberry Pi Pixhawk F3 CC3D Betaflight F4 Aircraft Flight Control RC FPV Drone

BN220 gps module has flash to save configuration, so you do not need to reset data when you use it next time. But it has no compass. If you need gps with flash and compass, please buy bn-880 gps. | When you use it for Raspberry Pi, there is no driver installation needed but you need to install software | TX LED flash means gps module output normally, and PPS LED flash means gps module locate your place. | Data Level : TTL or RS-232,Default TTL level. To make it be RS232 output, you need to use one TTL to RS232 converter cable | If you have any problem, please contact seller as follow: click "DIYmalls"(you can find "Sold by DIYmalls" under Buy Now button), in the new page, click "Ask a question".
Manufacturer: NEXTION

All major credit & debit cards accepted securely:

₹197.00
Imported from USA to INDIA

Use 220V to 110V Adapter for Electronic appliances

Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Specification Dimension :?22mm*20mm*6mm Connector : 1.00mm spacing between the 4pins patch seat Chipset : 8th Receiving Format :?GPS,GLONASS,Galileo,BeiDou,QZSS and SBAS Frequency : GPS L1,GLONASS L1,BeiDou B1,SBAS L1,Galileo E1 Channels : 72 Searching ChannelSensitivity Tracking : -167dBm Reacquisition : -160dBm Cold start : -148dBm Hot start : -156dBmAccuracy Position Horizontal : 2.0 m CEP 2D RMS SBAS Enable (Typical Open Sky) Velocity : 0.1m/sec 95% (SA off) Timing : 1us synchronized to GPS timeAcquisition Time Cold Start : 26s Warm start : 25s Hot start : 1sData and Update Rate Support Rate : 4800bps to 921600bps,Default 9600bps Data Level : TTL or RS-232,Default TTL level Data Protocol : NMEA-0183 or UBX, Default NMEA-0183 Single GNSS : 1Hz-18Hz Concurrent GNSS : 1Hz-10Hz,Default 1HzOperational Limits Altitude : 50,000m Max Velocity : 515m/s Max Acceleration : Less than 4gPower consumption VCC : DC Voltage 3.0V-5.5V,Typical: 5.0V Current : Capture 50mA/5.0V Operating temp :?-40 °C to +85°C Storage Temp : -40°C to +105°CIndicator: TX LED:blue.The data output, TX LED flashing PPS LED:red.PPS LED not bright when GPS not fixed,flashing when fixedWiring: GND,TX output,RX input,VCC(3.0v-5.5v)Package Included: 1 x BN-220 GPS Module 2 x 15cm Cable
