Product Functions
PTZ controller
Video signal testing
DC12V 1A output power
Image generator: Multi-format video OUT port image generator, sending a variety of standard (e.g. PAL, NTSC) color graphics section
Audio testing: Test the audio input from pickup devices. Connect the tester and pickup device with the audio cable.
Enhanced network cable testing: By UTP CABLE TEST port on the meter, you can test the connection of network cable.
VGA/HDMI input: Support VGA/HDMI 1.1 Compliant Digital input, once connect VGA/HDMI video, please switch selector to select HDMI or VGA mode.
TVI camera test: HD TVI video surveillance testing, support 1MP, 2MP, 3MP, 4MP, 5MP. When TVI signal input, the tester will display HD TVI camera image.
AHD camera test: HD video surveillance testing, support 1MP, 2MP, 3MP, 4MP, 5MP. When AHD signal input, the tester will display the AHD camera image.
CVI camera test: HD video surveillance testing, support 1MP, 2MP, 3MP, 4MP. When CVI signal input, the tester will display the CVI camera image.
LED lamp: It is useful for the engineer to install and maintain security system at night; LED On/Off pressing button, easy to operate.

Feature
Language settings: English, Chinese, Korean, Russian, Italian, French, Polish, Spanish, Japanese etc
Auto power off: 1-30 (mins)
Working Temperature: -10?---+50?
Humidity: 30%-90% Rh
Dimension: 221mm x 175mm x 91mm
Weight: 0.75kg

Packing list
1X HD coaxial tester
1X Adapter DC5V 1.5A?with USB cable)
1X International Standard 18650 2600ma battery
1X BNC cable
1X RS485 connector
1X Power output conversion cable
1X Audio cable
1X Lanyard
1X Tool bag
1X Instruction Manual
